The FA 17 is a high-end LED moving head light developed by FINE ART for the premium performance market. It integrates beam, dyeing(wash), patterning(gobo) and framing. Equipped with a newly customized 1600W LED white-light module, it delivers higher light output, fuller beams, and outstanding long-throw performance. The color system is optimized for the light source, ensuring pure, rich, and color transitions(pure color, more delicate and abundant color transitions). The fixture features an absolute positioning system, providing fast and accurate horizontal/vertical reset responses to meet the demanding placement requirements of complex stage designs. It includes 2 color wheels, 2 rotating pattern wheels, 1 effects wheel, and a full-range framing system that rotates ±90° with sharp, distortion-free edges. Compact in size with uniform light distribution, it is suitable for cultural tourism projects, outdoor live performances, large stadiums, TV studios, theatres, stages, concerts, galas, auto shows, and more.

The FA 17C is a professional multi-spectrum framing moving head light launched byFINE ART for the high-end performance market. Equipped with a revolutionary 1600W six-color LED module, it delivers exceptional long-throw performance, achieving an intensity of up to 7600 lux at a distance of 20 meters. It provides powerful light output, excellent light quality, and precise color control for stage productions. Utilizing an RGBALC color mixing system, the FA 17C not only supports virtual CMY and virtual CTO but also achieves a wide color gamut and smooth color transitions to meet diverse color design requirements. The fixture features an absolute positioning system, offering fast and quiet horizontal/vertical reset responses with precise positioning to meet the stringent placement demands of complex stage designs. It includes 1 color wheel, 2 rotating pattern wheels, 1 effects wheel, and a full-range framing system that rotates ±90° with sharp, distortion-free edges. Designed as a multi-spectrum framing light for long-distance, high-demand applications, the FA 17C has become a professional solution for stage and theatrical performances, thanks to its outstanding optical performance and precise color control.

The FA 500 BSW IP is a versatile laser moving head developed by FINE ART , integrating beam, pattern, and wash functions into one fixture. Powered by a robust 500W laser source with a beam angle as narrow as 0.8°, it projects sharp, highly penetrating aerial beam effects. The color system employs CMY continuous color mixing, complemented by a 17-color independent color wheel and an adjustable-speed rainbow effect, ensuring smooth color transitions. It features a dual gobo system combined with an independent effects wheel, allowing layered dynamic effects such as chase, shake, and rotation. Equipped with an 8-facet prism and a 24-facet prism, along with linear dimming, an independent frost filter, and strobe, it effortlessly creates multi-layered, high-impact stage visuals. Designed with an IP66 rating and an advanced thermal management system, the fixture ensures stable and reliable performance. Compact, lightweight, and user-friendly, it is suitable for cultural tourism projects, outdoor live performances, large stadiums, theaters, stages, concerts, galas, and more.

The FA 300 BEAM IP is a revolutionary all-weather laser moving beam light. It utilizes a 280W laser source and a high-efficiency, large-aperture optical lens, capable of instantly producing pure, impactful, and penetrating beams. With an IP66 protection rating, the fixture is designed to withstand harsh weather conditions, making it perfectly suited for outdoor use, while its innovative structural design maintains a compact and lightweight form factor comparable to indoor fixtures. It features a CMY continuous color mixing system and one independent color wheel with 17 color filters, ensuring smooth and rich color reproduction. Additionally, it includes one fixed pattern wheel with 19 patterns and is equipped with both an 8-facet prism and a 24-facet prism, enabling the creation of multi-layered, dynamic, and versatile spatial lighting effects. The FA 300 BEAM IP is your ideal lighting partner for both indoor and outdoor performances and events, making every occasion shine brilliantly!

The FINE 1700LC iSPOT - A full-spectrum LED moving head light dedicated to the high-end performance market. It incorporates a 1500W RGBLA LED custom light engine and an independently developed color management system to guarantee color consistency, purity, and a broad color gamut. Utilizing a patented heat dissipation system, it can sustain full-power operation at normal temperatures without power reduction, with noise levels lower than 45dB. Equipped with 1 rotating gobo wheel, 1 dynamic wheel, and a full-range framing system capable of ±90° rotation, featuring clear edges and no distortion. Compact in size and lightweight, it is applicable to places with high requirements for light quality such as television stations, theaters, and concerts. The head of the FINE 1700LC iSPOT is outfitted with a high-definition digital camera, which can be connected via optical fiber or Ethernet to the FINE iSPOT PILOT console for tracking and following moving figures or targets on the stage.

FINE iSPOT PILOT ground follow system solves the problems of traditional follow spot operation. For venues such as sports stadiums, theaters, concert halls, and TV studios, where high-altitude operations or limited space are required, it allows easy control of multiple follow spot lights from the ground. This system effortlessly achieves effects that traditional follow spot lights cannot accomplish, thereby reducing equipment installation time and operating costs.

FINE 1700LH iSPOT IP is an all-weather LED moving head light that integrates beam, dyeing, pattern and cutting functions specially created for the high-end indoor and outdoor performance market. The luminaire has an excellent range, effective range of up to 100 meters, while providing excellent light quality performance. Its patented cooling technology enables the lamps to operate at full power at normal temperature, without power reduction and with noise as low as 45dB. The lamps use second-generation color standards to ensure color consistency and a wide color gamut. Rich functional configuration, including two color wheels, a total of 12 color sheets, two rotating pattern plates, a dynamic effect wheel and a set of ±90° rotation of the whole cutting system, cutting edge clear and distortion free. In addition, the whole lamp is designed to achieve IP66 protection, and the aluminum die-cast housing ensures stable operation in all weather conditions. The head of the lamp body is integrated with a high-definition digital camera, and the operator can remotely control the horizontal rotation, vertical rotation, zoom and autofocus functions of the lamp through the head, and track the actors on stage from a "first-person perspective."

The FINE 1700LC iSPOT - A full-spectrum LED moving head light dedicated to the high-end performance market. It incorporates a 1500W RGBLA LED custom light engine and an independently developed color management system to guarantee color consistency, purity, and a broad color gamut. Utilizing a patented heat dissipation system, it can sustain full-power operation at normal temperatures without power reduction, with noise levels lower than 45dB. Equipped with 1 rotating gobo wheel, 1 dynamic wheel, and a full-range framing system capable of ±90° rotation, featuring clear edges and no distortion. Compact in size and lightweight, it is applicable to places with high requirements for light quality such as television stations, theaters, and concerts. The head of the FINE 1700LC iSPOT is outfitted with a high-definition digital camera, which can be connected via optical fiber or Ethernet to the FINE iSPOT PILOT console for tracking and following moving figures or targets on the stage.

TEKMAND G3 ULTRA is the third generation intelligent digital dimming console and has completely independent intellectual property rights. Adopting the ultimate hardware configuration and ultimate performance, it can easily cope with extremely large lighting systems. TEKMAND G3 ULTRA's new dual-system architecture, newly designed multi-screen application interaction, simple interface, rich graphics and text, and dual protection of software and hardware provide a safer and more reliable programming environment. Infrared, fingerprint scanner, dual cameras, dual-turn encoders, electric pushrods with scale backlight, voice recognition, remote assistant, AI programming and other new usages are added to experience different lighting programming and feel the charm brought by TEKMAND G3 .

TEKMAND G3 Pro is the third-generation intelligent lighting console, featuring fully owned intellectual property. Equipped with industrial-grade hardware and a dual-system architecture, its robust performance seamlessly manages ultra-large lighting systems. Cutting-edge features include AI-powered programming, voice control, fingerprint recognition, motorized faders with backlit scale, infrared sensing and dual-camera real-time previews, providing an efficient, intelligent lighting programming experience.

TEKMAND NANO has a delicate and portable shape, simple interface and rich functions; The volume is about the same as A4 paper, which is convenient to carry around, built-in WIFI, battery, and realizes pure wireless control of lights. Supports pre-programming in the offline state, saving a lot of time and improving work efficiency. The TEKMAND system itself can process 2048 parameters, and can control various types of lighting equipment through external extenders, such as conventional lamps, moving head lights, LED lights, video and media digital lights, etc.

TEKMAND E3 is a series of high-productivity lighting consoles independently developed by our company, tailored specifically for lighting designers and boasting complete independent intellectual property rights.TEKMAND E3 is more than a series of industry-leading lighting control hardware—it is your reliable companion during long work sessions, a meticulously crafted workspace. Whether controlling traditional lights, moving lights, pixel effect lights, or automated media devices, it is designed to put you fully in command of your artistic creations.All products in the TEKMAND E3 series adopt the same TEKMAND system and software, ensuring you a consistent experience every time you use a TEKMAND console.Equipped with a host of advanced features—including an AI agent, motorized faders with backlit scales, dual-ring touch encoders, and fully customizable backlight colors for the entire panel—the TEKMAND E3 offers a streamlined and intuitive control interface. It delivers a comfortable operating experience and flexible personalized customization, capable of running the most complex lighting systems, making it an ideal professional lighting console.

The FD 500T Chain Hoist, the latest R&D achievement from FINE DAX, is a medium-duty hoisting device with a rated load capacity of 500 kg. It can be paired with a matching VFD-axis controller for programmable control and high-precision positioning. The hoist achieves a maximum operating speed of 30 m/min, with a linear positioning error controlled within ±1 mm. It integrates dual electromagnetic brakes, four-point stroke limiters, and a safety design compliant with C1 standards, featuring a chain safety factor of 10:1. A built-in load cell provides weight monitoring, offering crucial data reference and risk warnings for lifting operations. With an IP66 protection rating, it operates stably under various environmental conditions, making it suitable for stage machinery applications that demand high precision and safety.

FD Hoistar is a multifunctional human-computer interaction stage mechanical console independently developed by FINE ART. Adopting Linux system architecture, Intel i5 processor, high-performance independent graphics card, dual 17.3-inch LCD touch screens, electric push rods with backlight and photoelectric encoder, application interaction is fast and smooth; DMP foot pedal, local emergency stop, built-in UPS, user Multiple software and hardware security guarantees such as permission setting, face recognition, operating parameter safety warning, closed-loop control, 3D visual monitoring of the motion status of all axes, etc.; supports 100M Ethernet and optical fiber communication, and can quickly send and receive control instructions and feedback information; tabular Programming, object-based programming, offline CUE programming, import of three-dimensional materials and CAD (3DS) format objects, 3D graphic control, visual offline operations, etc., making programming and control simple and easy to use; supports LTC time code triggering and DMX512 communication, supports Up to 999 channel groups and 999 CUE capacity. It is the best choice for stage machinery control in theaters, studios, shows, concerts and other places.

The FD PDES CNC System Cabinet is an integrated power distribution and main control unit designed by FD for stage machinery and large-scale performance systems. It provides power management, safety control, and system expansion capabilities, supporting the daisy-chaining of multiple units to enhance the overall system's safety redundancy and reliability. It features remote emergency stop and emergency stop link expansion, complies with Category 0 and Category 1 safety emergency stop standards, and integrates multiple electrical protection mechanisms including short-circuit, leakage, and over-current protection.

The FD VFD 3 IP-Axis Controller is a high-performance drive designed by FD specifically for controlling three-phase asynchronous motor hoists. It can be networked and programmed via the FD ONPC control system or FD mechanical console to achieve high-precision positioning and complex trajectory motion control for single or multiple hoists. Utilizing vector motion control algorithms, it achieves positioning accuracy within ±1 mm and features zero-speed hovering, fast dynamic torque response, and dual-encoder verification for stable motion control. The controller integrates multiple safety protections including over-current, overload, under-voltage, and software limits, and complies with SIL3 functional safety standards with an exceptional response time not exceeding 200 μs. It is suitable for hoisting applications in stage machinery that demand high precision, safety, and programmable control.
