Input: Interface uses a 400A European-style self-locking 'Rhinoceros' connector. Three-phase five-wire AC380V ±10%, frequency 50/60 Hz
Output: 8 three-phase five-wire 32A aviation sockets, 4 single-phase 16A aviation sockets. Each output circuit is equipped with an independent switch and indicator light
Supports 100M Ethernet communication and fiber optic communication
Supports remote emergency stop and emergency stop link expansion, compliant with Category 0 and Category 1 safety emergency stop standards
Equipped with a three-phase intelligent power meter
Built-in cabinet lighting, with one light each on the front and rear
Built-in 250A main switch; power distribution includes short-circuit protection, leakage protection, and other functions
Input: Interface uses a 400A European-style self-locking 'Rhinoceros' connector. Three-phase five-wire AC380V ±10%, frequency 50/60 Hz
Output: 8 three-phase five-wire 32A aviation sockets, 4 single-phase 16A aviation sockets. Each output circuit is equipped with an independent switch and indicator light
Supports 100M Ethernet communication and fiber optic communication
Supports remote emergency stop and emergency stop link expansion, compliant with Category 0 and Category 1 safety emergency stop standards
Equipped with a three-phase intelligent power meter
Built-in cabinet lighting, with one light each on the front and rear
Built-in 250A main switch; power distribution includes short-circuit protection, leakage protection, and other functions
Dimensions: 700 x 630 x 1000 mm
Weight: 109 kg
Dimensions: 700 x 630 x 1000 mm
Weight: 109 kg
Ambient Temperature: 0℃ to +45℃
Relative Humidity: +40% to +80%
Atmospheric Pressure: 0.8 to 1.6 standard atmospheres
Operating Environment: Well-ventilated, free from excessive smoke and dust
Ambient Temperature: 0℃ to +45℃
Relative Humidity: +40% to +80%
Atmospheric Pressure: 0.8 to 1.6 standard atmospheres
Operating Environment: Well-ventilated, free from excessive smoke and dust
