- Light source: (24CW+24WW) X 3W LED light source
Lifespan: ≥50000h
Light angle: 40~70 degrees
- Light source: (24CW+24WW) X 3W LED light source
Lifespan: ≥50000h
Light angle: 40~70 degrees
- Color temperature: 2800K~6500K
- Color temperature: 2800K~6500K
- Strobe: fast strobe, multiple strobe mode selection, pulsation, thunder and lightning, random
- Strobe: fast strobe, multiple strobe mode selection, pulsation, thunder and lightning, random
Channel control: Stand 11/Simp 7/Pixels 20
Communication protocol: standard DMX512/RDM protocol, wireless DMX512 (optional)
Menu display: black and white 1.3-inch OLED display;
Chinese/English language can be switched at will, font can be reversed 180° for display, button operation mode
Channel control: Stand 11/Simp 7/Pixels 20
Communication protocol: standard DMX512/RDM protocol, wireless DMX512 (optional)
Menu display: black and white 1.3-inch OLED display;
Chinese/English language can be switched at will, font can be reversed 180° for display, button operation mode
The upper and lower rows are independently controlled in 4 sections
Constant current driveIntelligent control and power adaptive technology
Cooling system: natural heat dissipationElectronic sensing detection
DMX channel level monitoring;Query lamp information, bulb usage time, and fault information through the display screen
With RDM data bidirectional transmission function
You can change the DMX address code, turn on and off the light bulb, reset the machine, and convert modes from the console
The software upgrade device can be connected to the DMX port of the lamp to upgrade the software
Input signal isolation protection function
The upper and lower rows are independently controlled in 4 sections
Constant current driveIntelligent control and power adaptive technology
Cooling system: natural heat dissipationElectronic sensing detection
DMX channel level monitoring;Query lamp information, bulb usage time, and fault information through the display screen
With RDM data bidirectional transmission function
You can change the DMX address code, turn on and off the light bulb, reset the machine, and convert modes from the console
The software upgrade device can be connected to the DMX port of the lamp to upgrade the software
Input signal isolation protection function
100 – 240V~, 50/60Hz
Maximum input power: 190W
Power factor PF: ≥0.95
100 – 240V~, 50/60Hz
Maximum input power: 190W
Power factor PF: ≥0.95
- Working temperature: -10°C ~40°C
- Working temperature: -10°C ~40°C
Product size: 984 x 139 x 102mm
Flight box size: 1127 x 502 x 533mm (including casters) Weight / 43 kg
Net weight: 8.2kg
Gross weight: 94kg
Product size: 984 x 139 x 102mm
Flight box size: 1127 x 502 x 533mm (including casters) Weight / 43 kg
Net weight: 8.2kg
Gross weight: 94kg
- 5 pc / flight case
- 5 pc / flight case
Install horizontally or vertically
2 pieces suitable for 40~60 cm Truss, integrated light hook
Safety rope connection hole
Install horizontally or vertically
2 pieces suitable for 40~60 cm Truss, integrated light hook
Safety rope connection hole
- IP20
- IP20
